LUMIN

LUMIN X1 DAC & Network Music Player

$13,990.00 USD
$13,990.00 USD
Sale Please Call 818-732-1448 To Order

The Cutting Edge Streamer: LUMIN X1

New processor delivering native DSD512 & PCM768 playback

Dual Mono design throughout maximizes channel separation

Dual ES9038Pro SABRE DACs featuring 140dB dynamic range

Fully balanced layout with high-quality components

Femto Clock System with precision FPGA distribution

Output connectors coupled with dual Lundahl LL7401 output transformers

New Output Buffer design

Dual Mono dual stage linear regulator

Optical Network provides complete isolation from network digital noise

USB Digital Audio Output supports Native DSD512

Entirely new power supply

New solid billet CNC casing design

Separate digital & analogue circuitry

Low-noise linear regulator

New 9-pin output connector

Specifications:

DSD support: Up to DSD512 22.6mhz, 1-bit

PCM support: Up to 768khz, 16–32-bit, stereo



Analog output stage: Dual ESS SABRE32 ES9038PRO DAC chips

Upsampling rates & bit depths: DSD128 upsampling option for all files

PCM 384kHz upsampling option for all files



Digital output stage

USB: Native DSD512 support,PCM 44.1–768kHz, 16–32-bit, stereo

BNC S/PDIF: PCM 44.1khz–192khz, 16–24-bit; DSD (DoP, DSD over PCM) 2.8mhz, 1-bit

Optical network: Industry-standard SFP,  1000base-T Eigabit Ethernet.

Dimensions

X1: 13.78” (w), 13.56”(d), 2.36” (h), 17.6 lbs

PSU: 4.17”mm (w), 13.15” (d), 2.36” (h), 8.8 lbs

  • From MQA to DSD, FLAC to WAV, LUMIN can play all the high-resolution formats you could ever want
  • Native support for TIDAL, Qobuz, Spotify and AirPlay-compatible, giving you access to tens of millions of songs
  • The unique and intuitive LUMIN App described as "the most convenient interface in existence" by TINMAN
  • Every LUMIN player comes with support for a wide range of popular streaming services including Roon, TIDAL, Qobuz, Spotify, FLAC Radio Stations and more
  • LEEDH Lossless volume control for all LUMIN players.

  • An innovative new digital volume adjustment algorithm that eliminates rounding errors is now included (at no additional cost) on all LUMIN players.
