Coda 07x FET Preamplifier

$6,500.00

    • Latest iteration of the '0' series preamplifiers,
    • featuring substantial active and passive component upgrades
    • Balanced and unbalanced inputs and outputs
    • Extremely low-noise circuitry with no overall feedback
    • May be operated with included CODA universal remote control
    • System logic remembers the most recent volume and balance settings for each input
    • Wide bandwidth regulated supply with AC EMI and RFI line filter
    • Double-sided gold-plated circuit boards
    • All anodized chassis
    • 10 year warranty / 5 year transferable

Frequency Response: -3dB @ 5Hz to 200kHz

Distortion: <.005% from 10Hz to 40kHz @ 5V peak into 600Ù or higher shunted by 1000pF

Gain: Unbalanced Output: 12dB @ 1kHz Balanced Output: 46db @ 1kHz

Maximum Output: 10V peak

Noise: <110dB referenced to 1V output
Input Impedance: 20kÙ

Output Impedance: 50Ù non-reactive unbalanced 100Ù non-reactive balanced

Crosstalk: 90dB @ 20kHz

Dimension: 18” W x 9.75” D x 2.5” H
