LUMIN U2 Transport Streamer
After the huge success of the sweetspot price/performance LUMIN T3, LUMIN U2 brings the same design philosophy to a transport- taking chassis construction methods, linear power supply design and dual-network from the multi-award-winning LUMIN P1, the all-new LUMIN U2 brings high-end digital right into the heart of the LUMIN range.
SPECIFICATIONS
DSD SUPPORT:
- Up to DSD512 22.5MHz, 1-bit
PCM SUPPORT:
- Up to 768kHz, 16–32-bit, Stereo
UPSAMPLING RATES & BIT DEPTHS:
- DSD256 upsampling option for all files
- PCM 384kHz upsampling option for all files
DIGITAL OUTPUT STAGE:
-
USB:
- Native DSD512 support
- PCM 44.1–768kHz, 16–32-bit, Stereo
-
OPTICAL, COAXIAL RCA, COAXIAL BNC & AES/EBU:
- PCM 44.1kHz–192kHz, 16–24-bit
- DSD (DoP, DSD over PCM) 2.8MHz, 1-bit
OPTICAL NETWORK:
- Industry-standard SFP
- 1000Base-T Gigabit Ethernet
- Adapter may be needed for your particular switch/cables
- Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN L1 or NAS)
POWER SUPPLY:
- Internal toroidal linear
- Low-noise linear regulator
DIMENSIONS: 13.8" (W), 13.8" (D), 2.4" (H), 13lbs
First LUMIN Transport to use new all-in-one chassis
Latest processor provides greater resampling flexibility
New integrated toroidal linear power supply
Fibre Network provides complete isolation from network digital noise
Increased capacity for future updates
3 USB ports including a NEW dedicated low-noise USB output Dual-Network interface with built-in Network Switch
DSD512 and PCM768 playback
4 exceptionally low-phase-noise crystal clock oscillators
New surface finish taken from the high-end P1
Leedh Processing lossless volume control
First LUMIN to feature 3 USB ports
New dedicated “Direct-Coupled” USB digital audio output port leaves two ports free for music storage and accessories
- From MQA to DSD, FLAC to WAV, LUMIN can play all the high-resolution formats you could ever want
- Native support for TIDAL, Qobuz, Spotify and AirPlay-compatible, giving you access to tens of millions of songs
- The unique and intuitive LUMIN App described as "the most convenient interface in existence" by TINMAN
- Every LUMIN player comes with support for a wide range of popular streaming services including Roon, TIDAL, Qobuz, Spotify, FLAC Radio Stations and more
- LEEDH Lossless volume control for all LUMIN players.
-
An innovative new digital volume adjustment algorithm that eliminates rounding errors is now included (at no additional cost) on all LUMIN players.
